Configuration Reference

See also: Oceans LLM Gateway, Runtime Bootstrap and Access, Service Accounts, Model Routing and API Behavior, Pricing Catalog and Accounting, OIDC and SSO

This page owns config syntax and parse-time rules. It does not own the full runtime story after a request starts moving.

Source of Truth

• config parsing and validation:
  • ../crates/gateway/src/config.rs
• provider capability defaults:
  • ../crates/gateway-core/src/domain.rs
• checked-in examples:
  • ../gateway.yaml
  • ../gateway.prod.yaml
  • ../deploy/config/gateway.yaml

Top-Level Sections

• server
• database
• auth
• budget_alerts
• request_logging
• providers
• models
• teams
• users

Value Sources

The config supports literal values and env references.

Common patterns:

• literal.admin
• env.OPENAI_API_KEY
• env.POSTGRES_URL

The YAML holds structure. Secrets and deploy-specific values usually come from the environment.

Minimal Local Example

server:
  bind: "127.0.0.1:8080"

database:
  kind: libsql
  path: "./var/oceans.db"

auth:
  bootstrap_admin:
    email: "admin@local"
    password: "literal.admin"
    require_password_change: false

providers:
  - id: openai
    type: openai_compat
    base_url: "https://api.openai.com/v1"
    pricing_provider_id: openai
    auth:
      kind: bearer
      token: env.OPENAI_API_KEY

models:
  - id: gpt-4o-mini
    routes:
      - provider: openai
        upstream_model: gpt-4o-mini

Production-Shaped Example

server:
  bind: "0.0.0.0:8080"

database:
  kind: postgres
  url: env.POSTGRES_URL

auth:
  bootstrap_admin:
    email: "admin@local"
    password: env.GATEWAY_BOOTSTRAP_ADMIN_PASSWORD
    require_password_change: true

providers:
  - id: vertex
    type: gcp_vertex
    project_id: env.GCP_PROJECT_ID
    location: global
    auth:
      mode: service_account
      credentials_path: env.GCP_SERVICE_ACCOUNT_JSON

teams:
  - key: platform
    name: Platform
    budget:
      cadence: monthly
      amount_usd: "500.0000"
      hard_limit: true
      timezone: UTC

users:
  - name: Platform Admin
    email: [email protected]
    auth_mode: password
    global_role: platform_admin
    membership:
      team: platform
      role: admin
    budget:
      cadence: monthly
      amount_usd: "100.0000"
      hard_limit: true
      timezone: UTC

models:
  - id: gemini-2.0-flash
    routes:
      - provider: vertex
        upstream_model: google/gemini-2.0-flash

The checked-in examples are opinionated. They are not the full config space.

Defaults That Matter

Important defaults from config parsing and domain deserialization:

• model rank defaults to 100
• route priority defaults to 100
• route weight defaults to 1.0
• route enabled defaults to true
• route capability flags default to all enabled
• Vertex location defaults to global
• Vertex api_host defaults to aiplatform.googleapis.com
• request_logging.payloads.capture_mode defaults to redacted_payloads
• request_logging.payloads.request_max_bytes defaults to 65536
• request_logging.payloads.response_max_bytes defaults to 65536
• request_logging.payloads.stream_max_events defaults to 128
• request_logging.purge.enabled defaults to false
• request_logging.purge.retention defaults to 7d

The startup meaning of bootstrap-admin lives in runtime-bootstrap-and-access.md. Non-human data-plane access is managed through service accounts, not config-seeded legacy runtime keys.

server

Important fields:

• bind
• log_format
• otel_endpoint
• otel_metrics_endpoint
• otel_export_interval_secs

For collector assumptions and request-log implications, see observability-and-request-logs.md.

request_logging

request_logging.payloads controls chat-completion request-log payload persistence.

request_logging:
  payloads:
    capture_mode: redacted_payloads
    request_max_bytes: 65536
    response_max_bytes: 65536
    stream_max_events: 128
    redaction_paths: []
  purge:
    enabled: false
    retention: 7d
    schedule: "0 0 * * *"

Important fields:

• capture_mode
  • disabled: skip chat-completion request-log persistence
  • summary_only: write summary rows with has_payload=false and no payload row
  • redacted_payloads: write summary rows and sanitized payload rows
• request_max_bytes: final persisted request payload budget
• response_max_bytes: final persisted response payload budget
• stream_max_events: maximum stored stream events; stream usage and error parsing still sees later frames
• redaction_paths: additive admin-configured redaction paths anchored from the wrapped payload root

Purge fields:

• purge.enabled
  • defaults to false
  • when true, the gateway starts a recurring request-log purge worker
• purge.retention
  • defaults to 7d
  • valid values are 1d, 3d, and 7d
• purge.schedule
  • standard 5-field cron expression for the recurring purge worker
  • defaults to 0 0 * * *
  • must describe a daily or less frequent schedule

Validation rules:

• byte limits must be greater than zero
• stream_max_events must be greater than zero
• redaction_paths use dot-separated object keys plus * as a full-segment wildcard
• malformed paths such as body..messages or indexed paths such as body.messages[0] are rejected at config parse time
• purge retention windows outside 1d, 3d, and 7d are rejected
• recurring purge schedules more frequent than daily are rejected, and the runtime guard also prevents more than one purge per day

The runtime redaction/truncation policy, purge command, and admin display behavior are owned by observability-and-request-logs.md.

database

The checked-in configs use two runtime shapes:

• local development:
  • libsql or SQLite with path
• production-shaped and deploy flows:
  • PostgreSQL with kind: postgres and url

Important fields:

• kind
  • libsql
  • postgres
• path
  • libsql or SQLite database path
  • defaults to ./gateway.db
• url
  • PostgreSQL connection URL
  • supports literal and env reference values
• max_connections
  • PostgreSQL pool size
  • defaults to 10

If kind is omitted, the gateway infers postgres when url is present and libsql otherwise. database.url is required when kind: postgres.

auth

Important fields:

• bootstrap_admin
• oidc.public_base_url
• oidc.providers
• oauth.public_base_url
• oauth.providers

Important distinctions:

• bootstrap_admin creates control-plane access
• bootstrap_admin.require_password_change changes first-login behavior
• bootstrap_admin.password must be literal.* or env.*

Seeded API keys are gateway caller credentials. They are useful for bootstrap automation and service-account workloads, but they are not upstream cloud provider service-account credentials. Each seeded key creates or reconciles an explicit gateway service account with an owning team and active budget.

Example seeded gateway key:

auth:
  seed_api_keys:
    - name: ci-indexer
      value: env.CI_INDEXER_GATEWAY_API_KEY
      service_account:
        key: ci-indexer
        name: CI Indexer
        team: platform
        budget:
          cadence: daily
          amount_usd: "25.0000"
          hard_limit: true
          timezone: UTC
      allowed_models:
        - gpt-4o-mini
        - gemini-fast

Operational guidance:

• store gateway API-key values in the deployment secret manager, not in YAML
• grant only the gateway models the workload needs
• declare the owning team in teams
• set a service-account budget before activating service-account traffic
• rotate by creating or seeding a replacement key, moving the caller, then revoking or removing the old key

OIDC providers use authorization-code login with provider discovery and ID-token verification:

auth:
  oidc:
    public_base_url: env.GATEWAY_PUBLIC_BASE_URL
    providers:
      - key: authentik
        label: Authentik
        issuer_url: https://auth.example.com/application/o/oceans-llm/
        client_id: oceans-llm
        client_secret: env.AUTHENTIK_OCEANS_LLM_CLIENT_SECRET
        scopes: [openid, email, profile]
        enabled: true

OAuth providers are separate from OIDC providers. GitHub is the first supported direct OAuth provider:

auth:
  oauth:
    public_base_url: env.GATEWAY_PUBLIC_BASE_URL
    providers:
      - key: github
        label: GitHub
        provider_type: github
        client_id: env.GITHUB_OAUTH_CLIENT_ID
        client_secret: env.GITHUB_OAUTH_CLIENT_SECRET
        scopes: [read:user, user:email]
        enabled: true
        jit:
          enabled: false

For GitHub setup steps and callback URL rules, see GitHub OAuth SSO Setup for Admins.

For startup behavior and first access after boot, use runtime-bootstrap-and-access.md.

Declarative Teams And Users

teams and users extend the same startup seed path used for providers and models.

Important teams fields:

• key
• name
• budget

Important users fields:

• name
• email
• auth_mode
• global_role
• request_logging_enabled
• oidc_provider_key
• oauth_provider_key
• membership.team
• membership.role
• budget

Validation rules that matter:

• team keys must be unique
• system-legacy has no reserved meaning and is not a compatibility owner
• user emails are normalized and must be unique
• admin@local is reserved for the bootstrap admin
• users[*].auth_mode supports password, oidc, and oauth
• oidc_provider_key is required for oidc users and rejected for password and oauth users
• oauth_provider_key is required for oauth users and rejected for password and oidc users
• membership roles can be admin or member
• membership role owner is rejected
• budget amounts must be non-negative

Seed semantics that matter:

• listed teams are upserted by teams[*].key
• listed users are upserted by normalized email
• new config-seeded users are created as invited
• listed membership and active-budget state is reconciled for listed users and teams
• omitting a budget block for a listed user or team deactivates that owner's active budget
• unlisted teams and users are left untouched

OIDC and OAuth provider existence is validated at seed time against enabled runtime providers, not YAML parse time.

Service accounts are managed by admins. They are not a replacement spelling for auth.seed_api_keys.

budget_alerts

budget_alerts.email controls the background email dispatcher for threshold alerts created by budget enforcement and budget updates.

budget_alerts:
  email:
    from_email: [email protected]
    from_name: "Oceans LLM"
    poll_interval_secs: 30
    batch_size: 25
    transport:
      kind: sink

Important fields:

• from_email
  • defaults to alerts@local
  • cannot be empty
• from_name
  • optional display name
• poll_interval_secs
  • defaults to 30
  • must be greater than zero
• batch_size
  • defaults to 25
  • must be greater than zero
• transport.kind
  • sink: persist alert delivery rows without sending email
  • smtp: send through SMTP

SMTP transport fields:

• host
• port
  • defaults to 587
• username
• password
• starttls
  • defaults to true

username and password must be set together when SMTP authentication is used. password supports the same secret-reference forms as other config secrets.

Provider Types

Supported provider types in the checked-in configs:

• openai_compat
• gcp_vertex
• aws_bedrock

Provider Auth Modes

Provider type	Auth field	Expected secret material
openai_compat	auth.token	bearer-style token
gcp_vertex	auth.mode: adc	ADC available in the runtime environment
gcp_vertex	auth.mode: service_account	upstream Google Cloud service-account JSON through credentials_path or an equivalent mounted secret path
aws_bedrock	auth.mode: bearer	Bedrock bearer token, often env.AWS_BEARER_TOKEN_BEDROCK

Provider auth config controls how the gateway authenticates to upstream providers. It is separate from gateway API keys, which authenticate callers to the gateway.

openai_compat

Important fields:

• id
• base_url
• pricing_provider_id
• auth.kind
• auth.token
• optional display.label
• optional display.icon_key

display.icon_key currently accepts the checked-in provider icon codes used by the admin UI:

• openai
• openrouter
• anthropic
• aws
• vertexai

Validation rules that matter:

• pricing_provider_id cannot be empty
• pricing_provider_id must map to a supported internal pricing family

gcp_vertex

Important fields:

• id
• project_id
• location
• api_host
• auth.mode
• optional display.label
• optional display.icon_key

Routing and pricing caveats:

• upstream_model must use <publisher>/<model_id>
• pricing identity is inferred from the publisher prefix
• Anthropic-on-Vertex pricing is only supported for location=global
• provider-specific configuration examples live in Google Vertex AI

aws_bedrock

Important fields:

• id
• region
• endpoint_url
  • optional
  • defaults to https://bedrock-runtime.{region}.amazonaws.com
• auth.mode
• default_headers
• timeouts.total_ms
• optional display.label
• optional display.icon_key

Runnable auth mode:

providers:
  - id: bedrock-api-key
    type: aws_bedrock
    region: us-east-1
    auth:
      mode: bearer
      token: env.AWS_BEARER_TOKEN_BEDROCK

default_chain and static_credentials use IAM SigV4 signing for Bedrock Runtime requests. bearer remains available for bearer-token based Bedrock access where applicable.

Routing caveats:

• upstream_model should be the Bedrock Runtime model identity passed to Bedrock APIs: a base model ID such as anthropic.claude-3-5-sonnet-20240620-v1:0, an inference profile ID such as us.anthropic.claude-3-5-sonnet-20240620-v1:0, or a supported Bedrock ARN.
• /v1/chat/completions routing is provider/model-specific in this slice: Claude non-streaming requests use InvokeModel with Anthropic Messages, while Bedrock Converse and ConverseStream are used for supported Bedrock-native chat flows.
• Route stream may be enabled for Bedrock models that support streaming through ConverseStream; keep responses and embeddings capability flags false.
• /v1/responses and /v1/embeddings are not implemented for aws_bedrock.
• Validate documentation-only updates with mise run docs-check.

Model Config

Configured gateway models are either:

• provider-backed models with routes
• alias-backed models with alias_of

A model cannot be both.

Important fields:

• id
• description
• tags
• rank
• routes
• alias_of

Route Config

Important fields:

• provider
• upstream_model
• priority
• weight
• enabled
• capabilities
• compatibility
• extra_headers
• extra_body

Capability flags default permissively. A route can constrain provider capability. It cannot expand provider truth.

Compatibility metadata is separate from capabilities. Capabilities decide whether a route may execute; compatibility describes explicit request and stream-shape transforms for the selected provider route.

Capability flags include API-family gates such as chat_completions, responses, and embeddings, plus feature gates such as stream, tools, vision, json_schema, and developer_role.

OpenAI-compatible route profile:

models:
  - id: fast
    routes:
      - provider: openrouter
        upstream_model: openai/gpt-4o-mini
        compatibility:
          openai_compat:
            supports_store: false
            max_tokens_field: max_tokens
            developer_role: system
            reasoning_effort: omit
            supports_stream_usage: true

OpenAI-compatible profile defaults:

Field	Default	Supported values
supports_store	true	true, false
max_tokens_field	max_completion_tokens	max_completion_tokens, max_tokens
developer_role	developer	developer, system
reasoning_effort	passthrough	passthrough, omit, reasoning_object
supports_stream_usage	false	true, false

The current openai_compat profile fields are Chat Completions transforms. /v1/responses is a separate supported API family and is not adapted by reusing Chat Completions compatibility shims.

Do not use extra_body for compatibility transforms. extra_body remains for additive provider-specific overrides, and the typed compatibility profile remains authoritative when a declared transform conflicts with an additive override.

Route Examples

OpenAI direct routes usually need no compatibility overrides:

models:
  - id: openai-direct
    routes:
      - provider: openai-prod
        upstream_model: gpt-5

OpenAI-compatible aggregator routes should declare known Chat Completions quirks explicitly:

models:
  - id: openrouter-fast
    routes:
      - provider: openrouter
        upstream_model: openai/gpt-4o-mini
        compatibility:
          openai_compat:
            supports_store: false
            max_tokens_field: max_tokens
            developer_role: system
            reasoning_effort: omit
            supports_stream_usage: true

Vertex Google routes use the Vertex provider and a publisher-qualified upstream model:

models:
  - id: gemini-fast
    routes:
      - provider: vertex-adc
        upstream_model: google/gemini-2.0-flash
        capabilities:
          chat_completions: true
          responses: false
          embeddings: false

Bedrock routes can execute Chat Completions through Claude native Messages, Converse, and ConverseStream depending on the upstream model and request shape. Keep Responses and embeddings disabled:

models:
  - id: claude-bedrock
    routes:
      - provider: bedrock
        upstream_model: us.anthropic.claude-3-5-sonnet-20240620-v1:0
        capabilities:
          chat_completions: true
          responses: false
          embeddings: false
          stream: true

OpenAI-compatible embeddings-only routes should narrow route capability so chat and Responses requests fail early:

models:
  - id: text-embedding
    routes:
      - provider: openai-prod
        upstream_model: text-embedding-3-small
        capabilities:
          chat_completions: false
          responses: false
          embeddings: true
          stream: false

Validation and Failure Boundaries

Config load catches several classes of failure up front:

• invalid or empty provider fields
• unsupported pricing-provider mappings
• invalid alias references
• invalid route or provider wiring

Later failures are usually runtime problems such as:

• request resolution failure
• missing providers
• capability mismatch
• exact-pricing gaps

Current Boundaries

• Declarative teams, password users, OIDC users, memberships, active budgets, and OIDC providers are part of the current seed contract.
• OIDC JIT defaults are provider configuration, not claim or group mapping.
• Existing password users are not auto-linked to SSO users by email.

What This Page Does Not Own

• startup behavior and first access:
  • runtime-bootstrap-and-access.md
• request routing and /v1/* behavior:
  • model-routing-and-api-behavior.md
• cross-cutting request cause and effect:
  • request-lifecycle-and-failure-modes.md
• spend windows and budget policy:
  • budgets-and-spending.md
• OIDC and SSO behavior:
  • oidc-and-sso-status.md
